规格型号 Specification

DRBQ160

DRBQ250

DRBQ315

DRBQ450

加热板表面温差 Surface Temperature Difference of the Heating Plate

≤±3°C

≤±3°C

≤±3°C

5±40C

液压系统工作压力范围
Operating Pressure Range of the Hydraulic System

1-7.0MPa

0-10.0MPa

0-13.0MPa

0-13.0MPa

加热板功率
Power of the Heating Plate

1.2KW

1.8KW

2.2KW

4.0KW

铣刀功率 Power of the Planing Tool

0.75KW

1.0KW

1.0KW

1.1KW

液压泵站功率
Power of the Hydraulic Pump Station

0.75KW

0.75KW

0.75KW

0.75KW

输入电压 Input Voltage

220V 50-60Hz

220V 50-60Hz

220V 50-60Hz

380V50-60HZ

输入功率 Input Power

3.0KW

3.6KW

4.0KW

6.0KW

焯接规格范围（mm) Fusion Range

63 90 110160

110160 200 250

160 200 250 315

315 355400450

整机净重 N.W. of the Equipment

110KG

130KG

190KG

240KG
